Magnitude |
:4.7 |
| Date & Time (UTC) | 2016-07-06 23:58:26.7 |
| Date & Time (Local) | 1395/4/17 04:28:26.7 |
| Location | Lat:27.703 Lon: 56.464 |
| Region | Hormozgan Province, 60 km North-East of Bandar-e abbas |
Nearest Cities |
|
| 42 km South East of Fareqan, Hormozgan Province | |
| 56 km North East of Fin, Hormozgan Province | |
| 60 km North East of Bandar-e abbas, Hormozgan Province | |
| 75 km West of Ziaratali, Hormozgan Province | |
| 79 km North West of Balashahr, Hormozgan Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| HZF2 (Length: 437 km) , Distance to epicenter: 4 km | |
| MAIN_ZAGROS_R_F (Length: 1106 km) , Distance to epicenter: 40 km | |
| ZENDAN_MINAB_F_Z1 (Length: 183 km) , Distance to epicenter: 49 km | |
| Number of Phases | 19 |
| RMS | 0.5 |
| Number of Stations | 17 |
| Error in Latitude | >9.5 km |
| Error in Longitude | 2.9 km |
| Error in Depth | 0 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 107389 | IIEES | KRBR | E | 8226.9 | 0.53 | 2016-07-06 23:59:42 | 2016-07-09 06:25:00 | n |
| 107390 | IIEES | KRBR | N | 5213 | 0.42 | 2016-07-06 23:59:42 | 2016-07-09 06:25:00 | n |
| 107391 | IIEES | AHRM | N | 488.5 | 0.86 | 2016-07-07 00:00:54 | 2016-07-09 06:25:00 | n |
| 107392 | IIEES | BSRN | E | 209 | 0.67 | 2016-07-07 00:01:05 | 2016-07-09 06:25:00 | n |
| 107393 | IIEES | BSRN | N | 321.5 | 0.47 | 2016-07-07 00:01:06 | 2016-07-09 06:25:00 | n |
| 107394 | IIEES | YZKH | E | 181.3 | 0.55 | 2016-07-07 00:00:43 | 2016-07-09 06:25:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | KRBR | Z | Pn | E | 2016-07-06 23:59:07 | 0.93 | n | 4 | 254 | 6 | ||
| IIEES | ZHSF | Z | Pn | E | 2016-07-06 23:59:32 | -0.47 | y | 472 | 62 | |||
| IIEES | AHRM | Z | Pn | E | 2016-07-06 23:59:39 | 0.36 | y | 523 | 285 | |||
| IIEES | BSRN | Z | Pn | E | 2016-07-06 23:59:41 | 0.65 | y | 538 | 28 | |||
| IIEES | YZKH | Z | Pn | E | 2016-07-06 23:59:42 | -0.09 | y | 550 | 341 | |||
| IIEES | TABS | Z | Pn | E | 2016-07-06 23:59:56 | 0.1 | y | 662 | 5 | |||
| IIEES | NASN | Z | Pn | E | 2016-07-06 23:59:57 | -0.22 | y | 666 | 329 | |||
| IIEES | SHRT | Z | Pn | E | 2016-07-07 00:00:08 | 0.52 | y | 754 | 28 | |||
| IIEES | GHVR | Z | Pn | E | 2016-07-07 00:00:26 | 0.24 | y | 901 | 328 | |||
| IIEES | KHMZ | Z | Pn | E | 2016-07-07 00:00:27 | -0.72 | y | 914 | 319 | |||
| IIEES | SHRO | Z | Pn | E | 2016-07-07 00:00:27 | -1 | y | 922 | 357 | |||
| IIEES | ASAO | Z | Pn | E | 2016-07-07 00:00:35 | -0.38 | y | 976 | 323 | |||
| IIEES | DAMV | Z | Pn | E | 2016-07-07 00:00:35 | -0.24 | y | 977 | 335 | |||
| IIEES | CHTH | Z | Pn | E | 2016-07-07 00:00:43 | -0.02 | y | 1041 | 332 | |||
| IIEES | MRVT | Z | P | E | 2016-07-07 00:00:51 | 0.34 | y | 1105 | 358 | |||
| IIEES | SNGE | Z | Pn | E | 2016-07-07 00:00:59 | -3.1 | n | 4 | 1192 | 316 | ||
| IIEES | GIDE | Z | Pn | E | 2016-07-07 00:01:03 | 0.6 | y | 1194 | 331 | |||
| IIEES | GRMI | Z | Pn | E | 2016-07-07 00:01:36 | -0.51 | n | 4 | 1467 | 329 | ||
| IIEES | MAKU | Z | P | E | 2016-07-07 00:02:03 | -0.33 | y | 1691 | 323 | |||
