Magnitude |
:3.2 |
| Date & Time (UTC) | 2017-08-23 16:28:35.6 |
| Date & Time (Local) | 1396/6/1 20:58:35.6 |
| Location | Lat:36.864 Lon: 55.216 |
| Region | Golestan Province, 18 km South of Ramian |
Nearest Cities |
|
| 18 km South of Ramian, Golestan Province | |
| 21 km West of Farsian, Golestan Province | |
| 22 km South of Khanduz, Golestan Province | |
| 23 km North of Kalateh khanj, Semnan Province | |
| 24 km South East of Deland, Golestan Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| SHAVAR_F (Length: 87 km) , Distance to epicenter: 10 km | |
| ROBATE_QARABIL_F (Length: 168 km) , Distance to epicenter: 20 km | |
| KHAZAR_F (Length: 523 km) , Distance to epicenter: 27 km | |
| Number of Phases | 15 |
| RMS | 0.4 |
| Number of Stations | 14 |
| Error in Latitude | >3.6 km |
| Error in Longitude | 3.8 km |
| Error in Depth | 8.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 118973 | IIEES | SHRO | E | 281.7 | 0.49 | 2017-08-23 16:29:13 | 2017-08-27 08:11:00 | n |
| 118974 | IIEES | BJRD | N | 242.6 | 0.61 | 2017-08-23 16:29:40 | 2017-08-27 08:11:00 | n |
| 118975 | IIEES | BJRD | E | 209.9 | 0.27 | 2017-08-23 16:29:42 | 2017-08-27 08:11:00 | n |
| 118976 | IIEES | DAMV | E | 76.7 | 0.58 | 2017-08-23 16:30:11 | 2017-08-27 08:11:00 | n |
| 118977 | IIEES | DAMV | N | 80.5 | 0.84 | 2017-08-23 16:30:17 | 2017-08-27 08:11:00 | n |
| 118978 | IIEES | TABS | N | 20.5 | 0.55 | 2017-08-23 16:30:40 | 2017-08-27 08:11:00 | n |
| 118979 | IIEES | THKV | N | 38.9 | 0.52 | 2017-08-23 16:30:33 | 2017-08-27 08:11:00 | n |
| 118980 | IIEES | THKV | E | 33.9 | 0.59 | 2017-08-23 16:30:36 | 2017-08-27 08:11:00 | n |
| 118981 | IIEES | GHVR | N | 24.8 | 0.67 | 2017-08-23 16:30:53 | 2017-08-27 08:11:00 | n |
| 118982 | IIEES | GHVR | E | 22.4 | 0.77 | 2017-08-23 16:31:00 | 2017-08-27 08:11:00 | n |
| 118983 | IIEES | GIDE | E | 19.9 | 0.64 | 2017-08-23 16:30:54 | 2017-08-27 08:11:00 | n |
| 118984 | IIEES | GIDE | N | 17.1 | 0.4 | 2017-08-23 16:31:00 | 2017-08-27 08:11:00 | n |
| 118985 | IIEES | YZKH | E | 10.2 | 0.34 | 2017-08-23 16:30:40 | 2017-08-27 08:11:00 | n |
| 118986 | IIEES | YZKH | N | 22.8 | 0.6 | 2017-08-23 16:30:41 | 2017-08-27 08:11:00 | n |
| 118987 | IIEES | ASAO | E | 6.3 | 0.71 | 2017-08-23 16:31:21 | 2017-08-27 08:11:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | MRVT | Z | Pg | E | 2017-08-23 16:28:55 | -0.09 | y | 117 | 41 | |||
| IIEES | SHRO | Z | Pg | E | 2017-08-23 16:28:55 | -0.24 | y | 119 | 143 | |||
| IIEES | BJRD | Z | Pn | E | 2017-08-23 16:29:10 | 0.09 | y | 215 | 64 | |||
| IIEES | BJRD | N | Sg | E | 2017-08-23 16:29:36 | 0.24 | y | 215 | 64 | |||
| IIEES | DAMV | Z | Pn | E | 2017-08-23 16:29:23 | 0.48 | y | 322 | 246 | |||
| IIEES | CHTH | Z | Pn | E | 2017-08-23 16:29:30 | -0.2 | y | 382 | 255 | |||
| IIEES | TABS | Z | Pn | E | 2017-08-23 16:29:32 | 0.19 | y | 396 | 154 | |||
| IIEES | THKV | Z | Pn | E | 2017-08-23 16:29:33 | 0.15 | y | 403 | 256 | |||
| IIEES | GHVR | Z | Pn | E | 2017-08-23 16:29:38 | 0.01 | y | 446 | 235 | |||
| IIEES | GIDE | Z | Pn | E | 2017-08-23 16:29:42 | 0.19 | y | 473 | 272 | |||
| IIEES | YZKH | Z | Pn | E | 2017-08-23 16:29:45 | -0.08 | y | 500 | 187 | |||
| IIEES | ASAO | Z | Pn | E | 2017-08-23 16:29:50 | 0.54 | y | 535 | 243 | |||
| IIEES | SHRT | Z | Pn | E | 2017-08-23 16:29:55 | -0.35 | y | 584 | 126 | |||
| IIEES | BSRN | Z | Pn | E | 2017-08-23 16:30:04 | -0.2 | y | 651 | 145 | |||
| IIEES | GRMI | Z | Pn | E | 2017-08-23 16:30:06 | -1.43 | y | 680 | 291 | |||
