Magnitude |
:4.2 |
| Date & Time (UTC) | 2017-10-18 17:35:36.9 |
| Date & Time (Local) | 1396/7/26 21:05:36.9 |
| Location | Lat:37.893 Lon: 47.149 |
| Region | Azarbaijan Sharghi Province, 28 km -East of Bostanabad |
Nearest Cities |
|
| 2 km of Sharabian, Azarbaijan Sharghi Province | |
| 8 km North of Sarcheshmeh, Azarbaijan Sharghi Province | |
| 18 km South of Mehraban, Azarbaijan Sharghi Province | |
| 19 km East of Kord kandi, Azarbaijan Sharghi Province | |
| 21 km North West of Abarghan, Azarbaijan Sharghi Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| BOZQUSH (Length: 70 km) , Distance to epicenter: 15 km | |
| N_TABRIZ_F1 (Length: 222 km) , Distance to epicenter: 24 km | |
| SANGAVAR_F (Length: 61 km) , Distance to epicenter: 104 km | |
| Number of Phases | 21 |
| RMS | 0.5 |
| Number of Stations | 17 |
| Error in Latitude | >3.2 km |
| Error in Longitude | 4.3 km |
| Error in Depth | 6.9 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 120626 | IIEES | GRMI | E | 5056.6 | 0.65 | 2017-10-18 17:36:20 | 2017-10-21 09:25:00 | n |
| 120627 | IIEES | ZNJK | E | 1578.1 | 0.42 | 2017-10-18 17:36:33 | 2017-10-21 09:25:00 | n |
| 120628 | IIEES | ZNJK | N | 1785.2 | 0.42 | 2017-10-18 17:36:34 | 2017-10-21 09:25:00 | n |
| 120629 | IIEES | GIDE | N | 1245.2 | 0.51 | 2017-10-18 17:37:05 | 2017-10-21 09:25:00 | n |
| 120630 | IIEES | GIDE | E | 761.4 | 0.71 | 2017-10-18 17:37:11 | 2017-10-21 09:25:00 | n |
| 120631 | IIEES | THKV | E | 457.4 | 0.62 | 2017-10-18 17:37:34 | 2017-10-21 09:25:00 | n |
| 120632 | IIEES | THKV | N | 368.8 | 0.27 | 2017-10-18 17:37:35 | 2017-10-21 09:25:00 | n |
| 120633 | IIEES | DAMV | E | 132.2 | 0.59 | 2017-10-18 17:38:11 | 2017-10-21 09:25:00 | n |
| 120634 | IIEES | GHVR | E | 161.8 | 1.13 | 2017-10-18 17:38:14 | 2017-10-21 09:25:00 | n |
| 120635 | IIEES | GHVR | N | 162.5 | 0.75 | 2017-10-18 17:38:15 | 2017-10-21 09:25:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GRMI | Z | Pg | E | 2017-10-18 17:35:56 | -0.57 | y | 121 | 32 | |||
| IIEES | GRMI | N | Sg | E | 2017-10-18 17:36:12 | 0.55 | y | 121 | 32 | |||
| IIEES | ZNJK | Z | Pg | E | 2017-10-18 17:36:07 | -0.77 | y | 192 | 134 | |||
| IIEES | ZNJK | N | Sg | E | 2017-10-18 17:36:31 | -0.3 | y | 192 | 134 | |||
| IIEES | GIDE | Z | Pn | E | 2017-10-18 17:36:18 | 0.13 | y | 267 | 113 | |||
| IIEES | MAKU | Z | Pn | E | 2017-10-18 17:36:18 | 0.14 | y | 269 | 308 | |||
| IIEES | MAKU | N | Sg | E | 2017-10-18 17:36:52 | -0.24 | y | 269 | 308 | |||
| IIEES | SNGE | Z | Pn | E | 2017-10-18 17:36:24 | 1.31 | n | 4 | 311 | 177 | ||
| IIEES | THKV | Z | Pn | E | 2017-10-18 17:36:34 | 0.1 | y | 398 | 122 | |||
| IIEES | CHTH | Z | Pn | E | 2017-10-18 17:36:36 | 0.05 | y | 417 | 121 | |||
| IIEES | DAMV | Z | Pn | E | 2017-10-18 17:36:46 | -0.06 | y | 498 | 119 | |||
| IIEES | KHMZ | Z | Pn | E | 2017-10-18 17:36:51 | 1.29 | y | 526 | 150 | |||
| IIEES | GHVR | Z | Pn | E | 2017-10-18 17:36:50 | 0.53 | y | 528 | 135 | |||
| IIEES | NASN | Z | Pn | E | 2017-10-18 17:37:20 | 0.39 | y | 764 | 136 | |||
| IIEES | MRVT | Z | Pn | E | 2017-10-18 17:37:21 | -0.7 | y | 788 | 89 | |||
| IIEES | SHRO | Z | Pn | E | 2017-10-18 17:37:26 | 0.55 | y | 816 | 102 | |||
| IIEES | BJRD | Z | Pn | E | 2017-10-18 17:37:36 | -0.73 | y | 903 | 88 | |||
| IIEES | YZKH | Z | Pn | E | 2017-10-18 17:37:38 | 0.22 | y | 912 | 130 | |||
| IIEES | TABS | Z | Pn | E | 2017-10-18 17:37:50 | -0.29 | y | 1016 | 115 | |||
| IIEES | BSRN | Z | Pn | E | 2017-10-18 17:38:22 | -0.2 | y | 1275 | 117 | |||
| IIEES | SHRT | Z | Pn | E | 2017-10-18 17:38:22 | -0.81 | y | 1277 | 108 | |||
