Magnitude |
:3.6 |
| Date & Time (UTC) | 2017-11-06 21:40:11.1 |
| Date & Time (Local) | 1396/8/16 01:10:11.1 |
| Location | Lat:36.974 Lon: 57.255 |
| Region | Khorasan(north) Province, 23 km -West of Esfarayen |
Nearest Cities |
|
| 9 km of Zarqabad, Khorasan(north) Province | |
| 17 km South of Cheharborj, Khorasan(north) Province | |
| 21 km South West of Eraj, Khorasan(north) Province | |
| 23 km West of Esfarayen, Khorasan(north) Province | |
| 24 km North East of Rivadeh, Khorasan(center) Province | |
| Depth | 15 km |
| Agency | |
Faults within 150 km: |
|
| ESFARAYEN_F (Length: 111 km) , Distance to epicenter: 20 km | |
| JOGHATAI_F (Length: 70 km) , Distance to epicenter: 44 km | |
| JAJARAM_F (Length: 77 km) , Distance to epicenter: 44 km | |
| Number of Phases | 15 |
| RMS | 0.4 |
| Number of Stations | 14 |
| Error in Latitude | >3.2 km |
| Error in Longitude | 5 km |
| Error in Depth | 8.1 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 121075 | IIEES | BJRD | N | 2301 | 0.43 | 2017-11-06 21:40:37 | 2017-11-07 04:54:00 | n |
| 121076 | IIEES | BJRD | E | 2450.8 | 0.54 | 2017-11-06 21:40:45 | 2017-11-07 04:54:00 | n |
| 121077 | IIEES | TABS | N | 111.3 | 0.63 | 2017-11-06 21:42:15 | 2017-11-07 04:54:00 | n |
| 121078 | IIEES | DAMV | E | 40.2 | 0.36 | 2017-11-06 21:42:44 | 2017-11-07 04:54:00 | n |
| 121079 | IIEES | YZKH | N | 20.2 | 0.55 | 2017-11-06 21:42:58 | 2017-11-07 04:54:00 | n |
| 121080 | IIEES | YZKH | E | 31.5 | 0.36 | 2017-11-06 21:43:08 | 2017-11-07 04:54:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | BJRD | Z | Pg | E | 2017-11-06 21:40:25 | -0.22 | y | 81.7 | 9 | |||
| IIEES | BJRD | N | Sg | E | 2017-11-06 21:40:35 | 0.12 | y | 81.7 | 9 | |||
| IIEES | MRVT | Z | Pg | E | 2017-11-06 21:40:32 | 0.23 | y | 128 | 307 | |||
| IIEES | SHRO | Z | Pg | E | 2017-11-06 21:40:36 | -0.19 | y | 154 | 226 | |||
| IIEES | TABS | Z | Pn | E | 2017-11-06 21:41:05 | 0.65 | y | 369 | 182 | |||
| IIEES | SHRT | Z | Pn | E | 2017-11-06 21:41:15 | -0.19 | y | 461 | 142 | |||
| IIEES | DAMV | Z | Pn | E | 2017-11-06 21:41:21 | 0.44 | y | 497 | 254 | |||
| IIEES | CHTH | Z | Pn | E | 2017-11-06 21:41:28 | -0.16 | y | 562 | 260 | |||
| IIEES | YZKH | Z | Pn | E | 2017-11-06 21:41:28 | -0.17 | y | 564 | 206 | |||
| IIEES | BSRN | Z | Pn | E | 2017-11-06 21:41:30 | -0.19 | y | 581 | 162 | |||
| IIEES | NASN | Z | Pn | E | 2017-11-06 21:41:35 | -0.32 | y | 616 | 223 | |||
| IIEES | KHMZ | Z | Pn | E | 2017-11-06 21:41:52 | -0.3 | y | 753 | 244 | |||
| IIEES | ZNJK | Z | Pn | E | 2017-11-06 21:41:54 | 0.74 | y | 765 | 270 | |||
| IIEES | KRBR | Z | Pn | E | 2017-11-06 21:41:55 | 0.24 | y | 777 | 184 | |||
| IIEES | GRMI | Z | Pn | E | 2017-11-06 21:42:02 | -1.4 | y | 848 | 287 | |||
