Magnitude |
:3.5 |
| Date & Time (UTC) | 2017-12-12 19:17:20.3 |
| Date & Time (Local) | 1396/9/21 22:47:20.3 |
| Location | Lat:30.733 Lon: 57.298 |
| Region | Kerman Province, 54 km North-East of Kerman |
Nearest Cities |
|
| 18 km North East of Harjand, Kerman Province | |
| 26 km North of Dehlulu, Kerman Province | |
| 31 km East of Hejdak, Kerman Province | |
| 39 km North East of Hutak, Kerman Province | |
| 40 km North East of Chatrud, Kerman Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| LAKARKUH_F (Length: 138 km) , Distance to epicenter: 11 km | |
| GOLBAF_SIRCH_F (Length: 114 km) , Distance to epicenter: 20 km | |
| KUHBANAN_F (Length: 189 km) , Distance to epicenter: 27 km | |
| Number of Phases | 12 |
| RMS | 0.4 |
| Number of Stations | 10 |
| Error in Latitude | >3.6 km |
| Error in Longitude | 4.3 km |
| Error in Depth | 7.8 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 124404 | IIEES | KRBR | N | 899.9 | 0.41 | 2017-12-12 19:17:49 | 2017-12-13 11:07:00 | n |
| 124405 | IIEES | BSRN | E | 504 | 0.43 | 2017-12-12 19:18:25 | 2017-12-13 11:07:00 | n |
| 124406 | IIEES | BSRN | N | 299.9 | 0.35 | 2017-12-12 19:18:25 | 2017-12-13 11:07:00 | n |
| 124407 | IIEES | YZKH | N | 82.3 | 0.43 | 2017-12-12 19:19:00 | 2017-12-13 11:07:00 | n |
| 124408 | IIEES | YZKH | E | 78.8 | 0.61 | 2017-12-12 19:19:08 | 2017-12-13 11:07:00 | n |
| 124409 | IIEES | TABS | N | 168.4 | 0.18 | 2017-12-12 19:19:03 | 2017-12-13 11:07:00 | n |
| 124410 | IIEES | SHRO | N | 13.2 | 0.49 | 2017-12-12 19:20:16 | 2017-12-13 11:07:00 | n |
| 124411 | IIEES | SHRO | E | 27.3 | 0.37 | 2017-12-12 19:20:21 | 2017-12-13 11:07:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | KRBR | Z | Pg | E | 2017-12-12 19:17:36 | -0.31 | y | 98 | 212 | |||
| IIEES | KRBR | N | Sg | E | 2017-12-12 19:17:49 | -0.42 | y | 98 | 212 | |||
| IIEES | BSRN | Z | Pn | E | 2017-12-12 19:17:55 | 0.14 | y | 221 | 51 | |||
| IIEES | BSRN | N | Sg | E | 2017-12-12 19:18:22 | -0.37 | y | 221 | 51 | |||
| IIEES | YZKH | Z | Pn | E | 2017-12-12 19:18:07 | -0.08 | y | 316 | 306 | |||
| IIEES | TABS | Z | Pn | E | 2017-12-12 19:18:07 | -0.32 | y | 324 | 357 | |||
| IIEES | ZHSF | Z | Pn | E | 2017-12-12 19:18:12 | 0.31 | y | 357 | 109 | |||
| IIEES | BNDS | Z | Pn | E | 2017-12-12 19:18:16 | 0.62 | y | 385 | 197 | |||
| IIEES | SHRT | Z | Pn | E | 2017-12-12 19:18:21 | 0.27 | y | 429 | 40 | |||
| IIEES | NASN | Z | Pn | E | 2017-12-12 19:18:29 | 0.89 | y | 483 | 299 | |||
| IIEES | GHIR | Z | Pn | E | 2017-12-12 19:18:29 | 0.01 | y | 498 | 238 | |||
| IIEES | SHRO | Z | Pn | E | 2017-12-12 19:18:41 | -0.49 | y | 597 | 349 | |||
