Magnitude |
:3.3 |
| Date & Time (UTC) | 2018-01-21 13:21:29.4 |
| Date & Time (Local) | 1396/11/1 16:51:29.4 |
| Location | Lat:33.881 Lon: 45.359 |
| Region | Iraq, 59 km South-West of Gilan-E-Gharb |
Nearest Cities |
|
| 26 km North West of Sumar, Kermanshah Province | |
| 58 km South West of Nian, Kermanshah Province | |
| 59 km South West of Khosravi, Kermanshah Province | |
| 59 km South West of Gilan-E-Gharb, Kermanshah Province | |
| 66 km South West of Seyyed sohrab, Kermanshah Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| ZFF4 (Length: 128 km) , Distance to epicenter: 12 km | |
| MFF7 (Length: 99 km) , Distance to epicenter: 41 km | |
| MFF8 (Length: 48 km) , Distance to epicenter: 83 km | |
| Number of Phases | 8 |
| RMS | 0.3 |
| Number of Stations | 6 |
| Error in Latitude | >7.7 km |
| Error in Longitude | 5.8 km |
| Error in Depth | 9.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 127357 | IIEES | SNGE | E | 292.7 | 0.42 | 2018-01-21 13:22:40 | 2018-01-22 11:22:00 | n |
| 127358 | IIEES | SNGE | N | 234.7 | 0.61 | 2018-01-21 13:22:41 | 2018-01-22 11:22:00 | n |
| 127359 | IIEES | KHMZ | E | 24.6 | 0.46 | 2018-01-21 13:23:17 | 2018-01-22 11:22:00 | n |
| 127360 | IIEES | KHMZ | N | 27.3 | 0.73 | 2018-01-21 13:23:43 | 2018-01-22 11:22:00 | n |
| 127361 | IIEES | ASAO | E | 24.7 | 0.5 | 2018-01-21 13:23:39 | 2018-01-22 11:22:00 | n |
| 127362 | IIEES | ASAO | N | 20.5 | 0.5 | 2018-01-21 13:23:43 | 2018-01-22 11:22:00 | n |
| 127363 | IIEES | GHVR | N | 20.1 | 0.72 | 2018-01-21 13:24:13 | 2018-01-22 11:22:00 | n |
| 127364 | IIEES | GHVR | E | 16.5 | 0.6 | 2018-01-21 13:24:22 | 2018-01-22 11:22:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | SNGE | Z | Pn | E | 2018-01-21 13:22:05 | 0.23 | y | 227 | 53 | |||
| IIEES | SNGE | N | Sg | E | 2018-01-21 13:22:33 | -0.16 | y | 227 | 53 | |||
| IIEES | SRSL | Z | Pn | E | 2018-01-21 13:22:09 | 0.03 | y | 259 | 2 | |||
| IIEES | KHMZ | Z | Pn | E | 2018-01-21 13:22:29 | -0.67 | y | 427 | 91 | |||
| IIEES | ZNJK | Z | Pn | E | 2018-01-21 13:22:30 | -0.07 | y | 433 | 43 | |||
| IIEES | ASAO | Z | Pn | E | 2018-01-21 13:22:31 | 0.38 | y | 436 | 79 | |||
| IIEES | ASAO | E | S | E | 2018-01-21 13:23:17 | 0.42 | y | 436 | 79 | |||
| IIEES | GHVR | Z | Pn | E | 2018-01-21 13:22:44 | -0.22 | y | 547 | 81 | |||
