Magnitude |
:3.3 |
| Date & Time (UTC) | 2018-11-05 06:05:51.5 |
| Date & Time (Local) | 1397/8/14 09:35:51.5 |
| Location | Lat:38.591 Lon: 48.671 |
| Region | Azerbaijan, 25 km North-West of Astara |
Nearest Cities |
|
| 21 km North East of Anbaran, Ardebil Province | |
| 24 km North of Kiladeh, Gilan Province | |
| 25 km North West of Astara, Gilan Province | |
| 25 km North East of Namin, Ardebil Province | |
| 26 km North East of Khaneh zeinian, Ardebil Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| TALESH_F (Length: 258 km) , Distance to epicenter: 10 km | |
| SANGAVAR_F (Length: 61 km) , Distance to epicenter: 43 km | |
| BOZQUSH (Length: 70 km) , Distance to epicenter: 57 km | |
| Number of Phases | 11 |
| RMS | 0.5 |
| Number of Stations | 10 |
| Error in Latitude | >5.1 km |
| Error in Longitude | 7.9 km |
| Error in Depth | 8.3 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 138274 | IIEES | GRMI | E | 3308.2 | 0.24 | 2018-11-05 06:06:13 | 2018-11-05 07:01:00 | n |
| 138275 | IIEES | GRMI | N | 1957 | 0.23 | 2018-11-05 06:06:15 | 2018-11-05 07:01:00 | n |
| 138276 | IIEES | GIDE | E | 186.4 | 0.32 | 2018-11-05 06:06:48 | 2018-11-05 07:01:00 | n |
| 138277 | IIEES | GIDE | N | 191.2 | 0.36 | 2018-11-05 06:06:50 | 2018-11-05 07:01:00 | n |
| 138278 | IIEES | MAKU | N | 39.7 | 0.41 | 2018-11-05 06:07:29 | 2018-11-05 07:01:00 | n |
| 138279 | IIEES | MAKU | E | 41.1 | 0.55 | 2018-11-05 06:07:35 | 2018-11-05 07:01:00 | n |
| 138280 | IIEES | THKV | N | 44.8 | 0.5 | 2018-11-05 06:07:23 | 2018-11-05 07:01:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES | GRMI | Z | Pg | E | 2018-11-05 06:06:04 | -0.02 | y | 71.8 | 290 | |||
| IIEES | ZNJK | Z | Pn | E | 2018-11-05 06:06:25 | -0.56 | y | 213 | 180 | |||
| IIEES | ZNJK | N | Sg | E | 2018-11-05 06:06:52 | -0.04 | y | 213 | 180 | |||
| IIEES | GIDE | Z | Pn | E | 2018-11-05 06:06:26 | 0.35 | y | 215 | 149 | |||
| IIEES | THKV | Z | Pn | E | 2018-11-05 06:06:43 | 0.19 | y | 356 | 146 | |||
| IIEES | MAKU | Z | Pn | E | 2018-11-05 06:06:43 | -0.09 | y | 356 | 285 | |||
| IIEES | CHTH | Z | Pn | E | 2018-11-05 06:06:44 | -0.56 | y | 369 | 143 | |||
| IIEES | SRSL | Z | Pn | E | 2018-11-05 06:06:47 | -0.06 | y | 390 | 228 | |||
| IIEES | SNGE | Z | Pn | E | 2018-11-05 06:06:49 | -0.17 | y | 406 | 197 | |||
| IIEES | DAMV | Z | Pn | E | 2018-11-05 06:06:54 | 0.16 | y | 440 | 137 | |||
| IIEES | ILBA | Z | Pn | E | 2018-11-05 06:07:14 | 1.3 | y | 594 | 203 | |||
