Magnitude |
:5.4 |
| Date & Time (UTC) | 2019-08-04 19:51:17.2 |
| Date & Time (Local) | 1398/5/14 00:21:17.2 |
| Location | Lat:30.62 Lon: 50.71 |
| Region | Kohkiluieh va boyerahmad Province, 23 km South-East of Dehdasht |
Nearest Cities |
|
| 23 km South East of Dehdasht, Kohkiluieh va boyerahmad Province | |
| 31 km North of Dogonbadan, Kohkiluieh va boyerahmad Province | |
| 31 km South of Savari, Kohkiluieh va boyerahmad Province | |
| 37 km North West of Abdehgah, Kohkiluieh va boyerahmad Province | |
| 39 km East of Mansuriyeh, Khoozestan Province | |
| Depth | 9 km |
| Agency | |
Faults within 150 km: |
|
| MISHAN_F (Length: 76 km) , Distance to epicenter: 5 km | |
| MFF4 (Length: 62 km) , Distance to epicenter: 44 km | |
| RAG_E_SEFID_F (Length: 84 km) , Distance to epicenter: 62 km | |
| Number of Phases | 38 |
| RMS | 0.4 |
| Number of Stations | 25 |
| Error in Latitude | >1 km |
| Error in Longitude | 0 km |
| Error in Depth | 10 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 144695 | IIEES SC | KLNJ | Z | 58000 | 1 | 2019-08-04 19:51:52 | 2019-08-05 12:45:00 | n |
| 144696 | IIEES SC | GTMR | Z | 32000 | 1 | 2019-08-04 19:52:49 | 2019-08-05 12:45:00 | n |
| 144697 | IIEES SC | KHMZ | Z | 6500 | 1 | 2019-08-04 19:52:57 | 2019-08-05 12:45:00 | n |
| 144698 | IIEES SC | GHVR | Z | 7900 | 1 | 2019-08-04 19:53:53 | 2019-08-05 12:45:00 | n |
| 144699 | IIEES SC | ASAO | Z | 4600 | 1 | 2019-08-04 19:53:39 | 2019-08-05 12:45:00 | n |
| 144700 | IIEES SC | ILBA | Z | 3000 | 1 | 2019-08-04 19:54:22 | 2019-08-05 12:45:00 | n |
| 144701 | IIEES SC | DAMV | Z | 1900 | 1 | 2019-08-04 19:54:46 | 2019-08-05 12:45:00 | n |
| 144702 | IIEES SC | KRBR | Z | 1600 | 1 | 2019-08-04 19:54:26 | 2019-08-05 12:45:00 | n |
| 144703 | IIEES SC | CHTH | Z | 1300 | 1 | 2019-08-04 19:54:32 | 2019-08-05 12:45:00 | n |
| 144704 | IIEES SC | KGS1 | Z | 6900 | 1 | 2019-08-04 19:53:57 | 2019-08-05 12:45:00 | n |
| 144705 | IIEES SC | TABS | Z | 1700 | 1 | 2019-08-04 19:54:52 | 2019-08-05 12:45:00 | n |
| 144706 | IIEES SC | ZNJK | Z | 580 | 1 | 2019-08-04 19:55:17 | 2019-08-05 12:45:00 | n |
| 144707 | IIEES SC | GIDE | Z | 4800 | 1 | 2019-08-04 19:55:21 | 2019-08-05 12:45:00 | n |
| 144708 | IIEES SC | SHRO | Z | 1300 | 1 | 2019-08-04 19:53:06 | 2019-08-05 12:45:00 | n |
| 144709 | IIEES SC | SRSL | Z | 1000 | 1 | 2019-08-04 19:54:38 | 2019-08-05 12:45:00 | n |
| 144710 | IIEES SC | MRVT | Z | 350 | 1 | 2019-08-04 19:53:25 | 2019-08-05 12:45:00 | n |
| 144711 | IIEES SC | SHRT | Z | 140 | 1 | 2019-08-04 19:54:19 | 2019-08-05 12:45:00 | n |
| 144712 | IIEES SC | ZHSF | Z | 100 | 1 | 2019-08-04 19:54:20 | 2019-08-05 12:45:00 | n |
| 144713 | IIEES SC | BJRD | Z | 230 | 1 | 2019-08-04 19:53:34 | 2019-08-05 12:45:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | KLNJ | Z | IP | I | 2019-08-04 19:51:33 | -0.1 | y | 100 | 63 | |||
| IIEES SC | GTMR | N | IP | I | 2019-08-04 19:51:57 | 0.7 | y | 255 | 324 | |||
| IIEES SC | BSR2 | Z | IP | I | 2019-08-04 19:52:02 | -0.1 | y | 300 | 263 | |||
| IIEES SC | KHMZ | Z | IP | I | 2019-08-04 19:52:10 | 1 | y | 355 | 349 | |||
| IIEES SC | GHVR | Z | IP | I | 2019-08-04 19:52:20 | 1.3 | y | 433 | 7 | |||
| IIEES SC | LMD1 | Z | IP | I | 2019-08-04 19:52:19 | 0.1 | y | 433 | 147 | |||
| IIEES SC | ASAO | Z | IP | I | 2019-08-04 19:52:21 | 1.1 | y | 444 | 352 | |||
| IIEES SC | ILBA | Z | IP | I | 2019-08-04 19:52:31 | -1.3 | y | 544 | 308 | |||
| IIEES SC | DAMV | Z | IP | I | 2019-08-04 19:52:36 | -0.2 | y | 567 | 12 | |||
| IIEES SC | KRBR | Z | IP | I | 2019-08-04 19:52:37 | -1.6 | y | 589 | 97 | |||
| IIEES SC | CHTH | Z | IP | I | 2019-08-04 19:52:38 | 0 | y | 589 | 4 | |||
| IIEES SC | ANJ | Z | IP | I | 2019-08-04 19:52:41 | -0.2 | y | 611 | 29 | |||
| IIEES SC | KGS1 | Z | IP | I | 2019-08-04 19:52:44 | -1.3 | y | 644 | 312 | |||
| IIEES SC | TABS | Z | IP | I | 2019-08-04 19:52:50 | -1 | y | 689 | 61 | |||
| IIEES SC | ZNJK | Z | IP | I | 2019-08-04 19:52:52 | -0.3 | y | 700 | 344 | |||
| IIEES SC | GIDE | Z | IP | I | 2019-08-04 19:52:52 | -0.1 | y | 700 | 354 | |||
| IIEES SC | SHRO | Z | IP | I | 2019-08-04 19:53:01 | -0.7 | y | 778 | 40 | |||
| IIEES SC | SRSL | Z | IP | I | 2019-08-04 19:53:03 | -0.1 | y | 789 | 322 | |||
| IIEES SC | MRVT | Z | IP | I | 2019-08-04 19:53:20 | -0.4 | y | 922 | 32 | |||
| IIEES SC | GRMI | Z | IP | I | 2019-08-04 19:53:22 | 0.1 | y | 945 | 344 | |||
| IIEES SC | SHRT | Z | IP | I | 2019-08-04 19:53:24 | -1.1 | y | 967 | 70 | |||
| IIEES SC | ZHSF | Z | IP | I | 2019-08-04 19:53:25 | -1.5 | y | 978 | 97 | |||
| IIEES SC | BJRD | Z | IP | I | 2019-08-04 19:53:29 | -0.4 | y | 1000 | 38 | |||
| IIEES SC | EIL | Z | IP | I | 2019-08-04 19:54:32 | -1.5 | y | 1523 | 266 | |||
| IIEES SC | KIV | Z | IP | I | 2019-08-04 19:54:49 | 0.4 | y | 1645 | 334 | |||
| IIEES SC | KLNJ | 1951 | 2019-08-04 19:51:55 | y | 100 | 63 | ||||||
| IIEES SC | GTMR | 1953 | 2019-08-04 19:53:00 | y | 255 | 324 | ||||||
| IIEES SC | KHMZ | 1953 | 2019-08-04 19:53:15 | y | 355 | 349 | ||||||
| IIEES SC | GHVR | 1953 | 2019-08-04 19:53:35 | y | 433 | 7 | ||||||
| IIEES SC | ASAO | 1953 | 2019-08-04 19:53:46 | y | 444 | 352 | ||||||
| IIEES SC | ILBA | 1954 | 2019-08-04 19:54:33 | y | 544 | 308 | ||||||
| IIEES SC | DAMV | 1952 | 2019-08-04 19:52:34 | y | 567 | 12 | ||||||
| IIEES SC | KRBR | 1954 | 2019-08-04 19:54:22 | y | 589 | 97 | ||||||
| IIEES SC | CHTH | 1954 | 2019-08-04 19:54:20 | y | 589 | 4 | ||||||
| IIEES SC | TABS | 1954 | 2019-08-04 19:54:59 | y | 689 | 61 | ||||||
| IIEES SC | ZNJK | 1955 | 2019-08-04 19:55:03 | y | 700 | 344 | ||||||
| IIEES SC | GIDE | 1955 | 2019-08-04 19:55:15 | y | 700 | 354 | ||||||
| IIEES SC | SRSL | 1954 | 2019-08-04 19:54:31 | y | 789 | 322 | ||||||
