Magnitude |
:5.6 |
| Date & Time (UTC) | 2019-10-21 10:58:52.4 |
| Date & Time (Local) | 1398/7/29 14:28:52.4 |
| Location | Lat:27.19 Lon: 55.08 |
| Region | Hormozgan Province, 71 km -East of Bastak |
Nearest Cities |
|
| 57 km North West of Bandar-e khamir, Hormozgan Province | |
| 71 km East of Bastak, Hormozgan Province | |
| 77 km North East of Bandar-e lengeh, Hormozgan Province | |
| 81 km North East of Jenah, Hormozgan Province | |
| 82 km South West of Darz, Fars Province | |
| Depth | 14 km |
| Agency | |
Faults within 150 km: |
|
| MFF1 (Length: 180 km) , Distance to epicenter: 16 km | |
| ZFF1 (Length: 165 km) , Distance to epicenter: 45 km | |
| LAR_F (Length: 99 km) , Distance to epicenter: 53 km | |
| Number of Phases | 28 |
| RMS | 0.5 |
| Number of Stations | 13 |
| Error in Latitude | >3 km |
| Error in Longitude | 0 km |
| Error in Depth | 5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 146869 | IIEES SC | LMD1 | Z | 180000 | 1 | 2019-10-21 10:59:56 | 2019-10-21 03:18:00 | n |
| 146870 | IIEES SC | AHRM | Z | 3800 | 1 | 2019-10-21 11:01:27 | 2019-10-21 03:18:00 | n |
| 146871 | IIEES SC | YZKH | Z | 3300 | 1 | 2019-10-21 11:01:49 | 2019-10-21 03:18:00 | n |
| 146872 | IIEES SC | YZKH | Z | 1500 | 0.89 | 2019-10-21 11:00:22 | 2019-10-21 03:18:00 | n |
| 146873 | IIEES SC | BSRN | Z | 4400 | 1 | 2019-10-21 11:02:14 | 2019-10-21 03:18:00 | n |
| 146874 | IIEES SC | BSRN | Z | 1000 | 1.49 | 2019-10-21 11:00:51 | 2019-10-21 03:18:00 | n |
| 146875 | IIEES SC | NASN | Z | 1600 | 1 | 2019-10-21 11:02:49 | 2019-10-21 03:18:00 | n |
| 146876 | IIEES SC | NASN | Z | 1200 | 0.74 | 2019-10-21 11:00:24 | 2019-10-21 03:18:00 | n |
| 146877 | IIEES SC | TABS | Z | 3600 | 1 | 2019-10-21 11:02:37 | 2019-10-21 03:18:00 | n |
| 146878 | IIEES SC | TABS | Z | 960 | 0.89 | 2019-10-21 11:00:39 | 2019-10-21 03:18:00 | n |
| 146879 | IIEES SC | GHVR | Z | 1700 | 1 | 2019-10-21 11:02:34 | 2019-10-21 03:18:00 | n |
| 146880 | IIEES SC | GHVR | Z | 760 | 0.86 | 2019-10-21 11:01:03 | 2019-10-21 03:18:00 | n |
| 146881 | IIEES SC | SHRO | Z | 150 | 0.71 | 2019-10-21 11:01:16 | 2019-10-21 03:18:00 | n |
| 146882 | IIEES SC | TBJM | Z | 250 | 0.96 | 2019-10-21 11:01:27 | 2019-10-21 03:18:00 | n |
| 146883 | IIEES SC | CHTH | Z | 200 | 1.29 | 2019-10-21 11:01:32 | 2019-10-21 03:18:00 | n |
| 146884 | IIEES SC | SBZV | Z | 160 | 0.88 | 2019-10-21 11:01:16 | 2019-10-21 03:18:00 | n |
| 146885 | IIEES SC | AKL | Z | 180 | 0.89 | 2019-10-21 11:01:28 | 2019-10-21 03:18:00 | n |
| 146886 | IIEES SC | MRVT | Z | 82 | 1 | 2019-10-21 11:01:50 | 2019-10-21 03:18:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | BNDS | Z | IP | I | 2019-10-21 10:59:12 | 1.5 | n | 4 | 111 | 78 | ||
| IIEES SC | LMD1 | Z | IP | I | 2019-10-21 10:59:22 | -0.3 | y | 189 | 275 | |||
| IIEES SC | KRBR | N | IP | I | 2019-10-21 10:59:24 | -19.4 | n | 4 | 355 | 28 | ||
| IIEES SC | AHRM | Z | IP | I | 2019-10-21 10:59:52 | 0.8 | y | 411 | 297 | |||
| IIEES SC | KLNJ | Z | IP | I | 2019-10-21 11:00:05 | -2.3 | n | 4 | 544 | 321 | ||
| IIEES SC | YZKH | Z | IP | I | 2019-10-21 11:00:12 | -0.1 | y | 578 | 355 | |||
| IIEES SC | BSRN | Z | IP | I | 2019-10-21 11:00:22 | 0.1 | y | 656 | 37 | |||
| IIEES SC | NASN | Z | IP | I | 2019-10-21 11:00:21 | -0.5 | y | 656 | 341 | |||
| IIEES SC | TABS | Z | IP | I | 2019-10-21 11:00:32 | -0.2 | y | 745 | 15 | |||
| IIEES SC | GHVR | Z | IP | I | 2019-10-21 11:00:50 | -0.4 | y | 889 | 336 | |||
| IIEES SC | SHRO | Z | IP | I | 2019-10-21 11:01:00 | -1.8 | y | 978 | 5 | |||
| IIEES SC | TBJM | Z | IP | I | 2019-10-21 11:01:08 | 0.9 | y | 1023 | 29 | |||
| IIEES SC | CHTH | Z | IP | I | 2019-10-21 11:01:08 | -0.8 | y | 1034 | 339 | |||
| IIEES SC | SBZV | Z | IP | I | 2019-10-21 11:01:09 | -0.9 | y | 1045 | 13 | |||
| IIEES SC | AKL | Z | IP | I | 2019-10-21 11:01:16 | -0.3 | y | 1100 | 18 | |||
| IIEES SC | MRVT | Z | IP | I | 2019-10-21 11:01:23 | -1.5 | y | 1167 | 5 | |||
| IIEES SC | AHRM | 11 | 2019-10-21 11:00:03 | y | 411 | 297 | ||||||
| IIEES SC | YZKH | Z | IVmB_BB | 2019-10-21 11:01:05 | y | 1 | 578 | 355 | ||||
| IIEES SC | BSRN | Z | IVmB_BB | 2019-10-21 11:01:15 | y | 1 | 656 | 37 | ||||
| IIEES SC | NASN | Z | IVmB_BB | 2019-10-21 11:00:54 | y | 1 | 656 | 341 | ||||
| IIEES SC | TABS | Z | IVmB_BB | 2019-10-21 11:01:01 | y | 1 | 745 | 15 | ||||
| IIEES SC | GHVR | Z | IVmB_BB | 2019-10-21 11:01:36 | y | 1 | 889 | 336 | ||||
| IIEES SC | SHRO | Z | IVmB_BB | 2019-10-21 11:01:43 | y | 1 | 978 | 5 | ||||
| IIEES SC | TBJM | Z | IVmB_BB | 2019-10-21 11:01:25 | y | 1 | 1023 | 29 | ||||
| IIEES SC | CHTH | Z | IVmB_BB | 2019-10-21 11:02:00 | y | 1 | 1034 | 339 | ||||
| IIEES SC | SBZV | Z | IVmB_BB | 2019-10-21 11:01:54 | y | 1 | 1045 | 13 | ||||
| IIEES SC | AKL | Z | IVmB_BB | 2019-10-21 11:01:27 | y | 1 | 1100 | 18 | ||||
| IIEES SC | MRVT | Z | IVmB_BB | 2019-10-21 11:02:13 | y | 1 | 1167 | 5 | ||||
