Magnitude |
:4.2 |
| Date & Time (UTC) | 2019-10-28 14:13:05.7 |
| Date & Time (Local) | 1398/8/6 17:43:05.7 |
| Location | Lat:34.48 Lon: 47.65 |
| Region | Kermanshah Province, 4 km of Sahneh |
Nearest Cities |
|
| 4 km of Sahneh, Kermanshah Province | |
| 4 km North of Darakeh, Kermanshah Province | |
| 7 km of Dehlaq, Kermanshah Province | |
| 7 km North of Gavgol-e olia, Kermanshah Province | |
| 11 km North East of Samangan, Kermanshah Province | |
| Depth | 31 km |
| Agency | |
Faults within 150 km: |
|
| SAHANEH_F (Length: 77 km) , Distance to epicenter: 9 km | |
| DINEHVAR_F (Length: 46 km) , Distance to epicenter: 15 km | |
| SARTAKHT_F (Length: 78 km) , Distance to epicenter: 29 km | |
| Number of Phases | 24 |
| RMS | 0.4 |
| Number of Stations | 25 |
| Error in Latitude | >1 km |
| Error in Longitude | 0 km |
| Error in Depth | 10 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 147044 | IIEES SC | KGS1 | Z | 6700 | 1 | 2019-10-28 14:13:38 | 2019-10-28 06:14:00 | n |
| 147045 | IIEES SC | KHMZ | Z | 2400 | 1 | 2019-10-28 14:14:17 | 2019-10-28 06:14:00 | n |
| 147046 | IIEES SC | ZNJK | Z | 670 | 1 | 2019-10-28 14:14:25 | 2019-10-28 06:14:00 | n |
| 147047 | IIEES SC | SRSL | Z | 3200 | 1 | 2019-10-28 14:14:33 | 2019-10-28 06:14:00 | n |
| 147048 | IIEES SC | MAHB | Z | 1500 | 1 | 2019-10-28 14:14:37 | 2019-10-28 06:14:00 | n |
| 147049 | IIEES SC | GHVR | Z | 2100 | 1 | 2019-10-28 14:14:58 | 2019-10-28 06:14:00 | n |
| 147050 | IIEES SC | THKV | Z | 610 | 1 | 2019-10-28 14:14:59 | 2019-10-28 06:14:00 | n |
| 147051 | IIEES SC | CHTH | Z | 510 | 1 | 2019-10-28 14:14:49 | 2019-10-28 06:14:00 | n |
| 147052 | IIEES SC | AZR | Z | 2600 | 1 | 2019-10-28 14:15:10 | 2019-10-28 06:14:00 | n |
| 147053 | IIEES SC | DAMV | Z | 340 | 1 | 2019-10-28 14:14:17 | 2019-10-28 06:14:00 | n |
| 147054 | IIEES SC | GRMI | Z | 210 | 1 | 2019-10-28 14:15:31 | 2019-10-28 06:14:00 | n |
| 147055 | IIEES SC | NASN | Z | 150 | 1 | 2019-10-28 14:15:56 | 2019-10-28 06:14:00 | n |
| 147056 | IIEES SC | KLNJ | Z | 230 | 1 | 2019-10-28 14:16:27 | 2019-10-28 06:14:00 | n |
| 147057 | IIEES SC | ANJ | Z | 80 | 1 | 2019-10-28 14:16:00 | 2019-10-28 06:14:00 | n |
| 147058 | IIEES SC | YZKH | Z | 110 | 1 | 2019-10-28 14:17:05 | 2019-10-28 06:14:00 | n |
| 147059 | IIEES SC | AHRM | Z | 44 | 1 | 2019-10-28 14:15:58 | 2019-10-28 06:14:00 | n |
| 147060 | IIEES SC | SHRO | Z | 51 | 1 | 2019-10-28 14:17:11 | 2019-10-28 06:14:00 | n |
| 147061 | IIEES SC | MRVT | Z | 28 | 1 | 2019-10-28 14:15:38 | 2019-10-28 06:14:00 | n |
| 147062 | IIEES SC | TABS | Z | 66 | 1 | 2019-10-28 14:15:15 | 2019-10-28 06:14:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | KGS1 | Z | IP | I | 2019-10-28 14:13:35 | 0 | y | 189 | 271 | |||
| IIEES SC | QABG | N | IS | I | 2019-10-28 14:14:04 | -0.6 | y | 222 | 52 | |||
| IIEES SC | QABG | Z | IP | I | 2019-10-28 14:13:38 | -1.7 | y | 222 | 52 | |||
| IIEES SC | KHMZ | Z | IP | I | 2019-10-28 14:13:40 | 0.2 | y | 233 | 111 | |||
| IIEES SC | ZNJK | Z | IP | I | 2019-10-28 14:13:44 | -0.4 | y | 255 | 21 | |||
| IIEES SC | SRSL | Z | IP | I | 2019-10-28 14:13:46 | -0.5 | y | 278 | 314 | |||
| IIEES SC | MAHB | Z | IP | I | 2019-10-28 14:13:50 | 0.4 | y | 311 | 325 | |||
| IIEES SC | GHVR | Z | IP | I | 2019-10-28 14:13:54 | 2 | y | 333 | 90 | |||
| IIEES SC | THKV | Z | IP | I | 2019-10-28 14:13:54 | 0.7 | y | 333 | 62 | |||
| IIEES SC | CHTH | Z | IP | I | 2019-10-28 14:13:56 | 0.2 | y | 355 | 63 | |||
| IIEES SC | AZR | Z | IP | I | 2019-10-28 14:14:00 | 0.6 | y | 389 | 337 | |||
| IIEES SC | DAMV | Z | IP | I | 2019-10-28 14:14:04 | 0.6 | y | 411 | 72 | |||
| IIEES SC | GRMI | Z | IP | I | 2019-10-28 14:14:11 | -0.2 | y | 478 | 3 | |||
| IIEES SC | NASN | Z | IP | I | 2019-10-28 14:14:16 | 0.8 | y | 511 | 111 | |||
| IIEES SC | KLNJ | Z | IP | I | 2019-10-28 14:14:17 | -0.6 | y | 533 | 136 | |||
| IIEES SC | ANJ | Z | IP | I | 2019-10-28 14:14:25 | 0.9 | y | 578 | 79 | |||
| IIEES SC | YZKH | Z | IP | I | 2019-10-28 14:14:37 | -0.2 | y | 689 | 110 | |||
| IIEES SC | AHRM | Z | IP | I | 2019-10-28 14:14:40 | 0.6 | y | 711 | 151 | |||
| IIEES SC | SHRO | Z | IP | I | 2019-10-28 14:14:49 | 0.3 | y | 778 | 77 | |||
| IIEES SC | MRVT | Z | IP | I | 2019-10-28 14:14:56 | 0.3 | y | 834 | 65 | |||
| IIEES SC | TABS | Z | IP | I | 2019-10-28 14:15:01 | 0.8 | y | 878 | 96 | |||
| IIEES SC | SBZV | Z | IP | I | 2019-10-28 14:15:06 | -1.2 | y | 934 | 77 | |||
| IIEES SC | BJRD | Z | IP | I | 2019-10-28 14:15:10 | 0.7 | y | 945 | 68 | |||
| IIEES SC | BSRN | Z | IP | I | 2019-10-28 14:15:29 | 0.1 | y | 1100 | 105 | |||
