Magnitude |
:3.6 |
| Date & Time (UTC) | 2020-08-15 02:23:14.5 |
| Date & Time (Local) | 1399/5/25 06:53:14.5 |
| Location | Lat:32.07 Lon: 47.5 |
| Region | Iraq, 73 km South-East of Dehloran |
Nearest Cities |
|
| 55 km South East of Musian, Ilam Province | |
| 60 km North West of Bostan, Khoozestan Province | |
| 72 km South West of Shush, Khoozestan Province | |
| 73 km South East of Dehloran, Ilam Province | |
| 74 km South West of Amaleh teimur, Khoozestan Province | |
| Depth | 10 km |
| Agency | |
Faults within 150 km: |
|
| MFF6 (Length: 144 km) , Distance to epicenter: 68 km | |
| AHVAZ_F (Length: 99 km) , Distance to epicenter: 78 km | |
| DEZFUL_EMBAYMENT (Length: 228 km) , Distance to epicenter: 85 km | |
| Number of Phases | 13 |
| RMS | 0.4 |
| Number of Stations | 13 |
| Error in Latitude | >3 km |
| Error in Longitude | 0 km |
| Error in Depth | 5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 156256 | IIEES SC | GTMR | Z | 860 | 1 | 2020-08-15 02:24:04 | 2020-08-16 09:21:00 | n |
| 156257 | IIEES SC | AMIS | Z | 950 | 1 | 2020-08-15 02:24:07 | 2020-08-16 09:21:00 | n |
| 156258 | IIEES SC | ILBA | Z | 160 | 1 | 2020-08-15 02:24:30 | 2020-08-16 09:21:00 | n |
| 156259 | IIEES SC | KHMZ | Z | 110 | 1 | 2020-08-15 02:24:49 | 2020-08-16 09:21:00 | n |
| 156260 | IIEES SC | SNGE | Z | 68 | 1 | 2020-08-15 02:24:51 | 2020-08-16 09:21:00 | n |
| 156261 | IIEES SC | ASAO | Z | 110 | 1 | 2020-08-15 02:25:06 | 2020-08-16 09:21:00 | n |
| 156262 | IIEES SC | KLNJ | Z | 120 | 1 | 2020-08-15 02:25:28 | 2020-08-16 09:21:00 | n |
| 156263 | IIEES SC | SRSL | Z | 57 | 1 | 2020-08-15 02:24:39 | 2020-08-16 09:21:00 | n |
| 156264 | IIEES SC | ZNJK | Z | 7.6 | 1 | 2020-08-15 02:24:43 | 2020-08-16 09:21:00 | n |
| 156265 | IIEES SC | CHTH | Z | 2.4 | 1 | 2020-08-15 02:24:48 | 2020-08-16 09:21:00 | n |
| 156266 | IIEES SC | MAHB | Z | 42 | 1 | 2020-08-15 02:25:32 | 2020-08-16 09:21:00 | n |
| 156267 | IIEES SC | DAMV | Z | 23 | 1 | 2020-08-15 02:26:07 | 2020-08-16 09:21:00 | n |
| 156268 | IIEES SC | DAMV | Z | 27 | 0.71 | 2020-08-15 02:24:33 | 2020-08-16 09:21:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | GTMR | Z | IP | I | 2020-08-15 02:23:41 | 0.3 | y | 155 | 74 | |||
| IIEES SC | AMIS | Z | IP | I | 2020-08-15 02:23:43 | 0.3 | y | 177 | 105 | |||
| IIEES SC | ILBA | Z | IP | I | 2020-08-15 02:23:49 | 0.4 | y | 211 | 325 | |||
| IIEES SC | KHMZ | Z | IP | I | 2020-08-15 02:23:59 | 0 | y | 300 | 51 | |||
| IIEES SC | SNGE | Z | IP | I | 2020-08-15 02:24:04 | 0 | y | 333 | 358 | |||
| IIEES SC | ASAO | Z | IP | I | 2020-08-15 02:24:08 | 0.2 | y | 366 | 41 | |||
| IIEES SC | KLNJ | Z | IP | I | 2020-08-15 02:24:12 | -0.6 | y | 411 | 107 | |||
| IIEES SC | QABG | Z | IP | I | 2020-08-15 02:24:18 | 0.5 | y | 444 | 26 | |||
| IIEES SC | SRSL | Z | IP | I | 2020-08-15 02:24:24 | -0.1 | y | 500 | 337 | |||
| IIEES SC | ZNJK | Z | IP | I | 2020-08-15 02:24:27 | -0.3 | y | 522 | 12 | |||
| IIEES SC | CHTH | Z | IP | I | 2020-08-15 02:24:29 | -0.6 | y | 544 | 38 | |||
| IIEES SC | MAHB | Z | IP | I | 2020-08-15 02:24:30 | -0.5 | y | 544 | 342 | |||
| IIEES SC | DAMV | Z | IP | I | 2020-08-15 02:24:32 | -1.2 | y | 567 | 46 | |||
