Magnitude |
:3.3 |
| Date & Time (UTC) | 2021-01-24 08:49:11.3 |
| Date & Time (Local) | 1399/11/5 12:19:11.3 |
| Location | Lat:32.06 Lon: 49.33 |
| Region | Khoozestan Province, 14 km North of Masjed Soleyman |
Nearest Cities |
|
| 14 km North of Masjed Soleyman, Khoozestan Province | |
| 19 km South West of Qale-yekhvaju, Khoozestan Province | |
| 26 km East of Haft shahidan, Khoozestan Province | |
| 31 km South East of Jaefarabad, Khoozestan Province | |
| 34 km South West of Paabshalal, Khoozestan Province | |
| Depth | 10 km |
| Agency | |
Faults within 150 km: |
|
| DEZFUL_EMBAYMENT (Length: 228 km) , Distance to epicenter: 14 km | |
| MFF2 (Length: 205 km) , Distance to epicenter: 25 km | |
| ZARDKUH_F (Length: 139 km) , Distance to epicenter: 75 km | |
| Number of Phases | 15 |
| RMS | 0.4 |
| Number of Stations | 12 |
| Error in Latitude | >3 km |
| Error in Longitude | 0 km |
| Error in Depth | 4 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 161208 | IIEES SC | AMIS | Z | 2600 | 1 | 2021-01-24 08:49:34 | 2021-01-24 01:05:00 | n |
| 161209 | IIEES SC | GTMR | Z | 2100 | 1 | 2021-01-24 08:49:31 | 2021-01-24 01:05:00 | n |
| 161210 | IIEES SC | KHMZ | Z | 170 | 1 | 2021-01-24 08:50:16 | 2021-01-24 01:05:00 | n |
| 161211 | IIEES SC | KLNJ | Z | 180 | 1 | 2021-01-24 08:50:28 | 2021-01-24 01:05:00 | n |
| 161212 | IIEES SC | ASAO | Z | 71 | 1 | 2021-01-24 08:50:47 | 2021-01-24 01:05:00 | n |
| 161213 | IIEES SC | GHVR | Z | 180 | 1 | 2021-01-24 08:51:26 | 2021-01-24 01:05:00 | n |
| 161214 | IIEES SC | SNGE | Z | 42 | 1 | 2021-01-24 08:51:03 | 2021-01-24 01:05:00 | n |
| 161215 | IIEES SC | CHTH | Z | 12 | 1 | 2021-01-24 08:51:31 | 2021-01-24 01:05:00 | n |
| 161216 | IIEES SC | DAMV | Z | 3.3 | 1 | 2021-01-24 08:51:47 | 2021-01-24 01:05:00 | n |
| 161217 | IIEES SC | YZKH | Z | 8.9 | 1 | 2021-01-24 08:51:44 | 2021-01-24 01:05:00 | n |
| 161218 | IIEES SC | GLO | Z | 24 | 1 | 2021-01-24 08:52:42 | 2021-01-24 01:05:00 | n |
| 161219 | IIEES SC | GLO | Z | 17 | 1.01 | 2021-01-24 08:51:02 | 2021-01-24 01:05:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | AMIS | Z | IP | I | 2021-01-24 08:49:19 | 0.1 | y | 44 | 186 | |||
| IIEES SC | GTMR | Z | IP | I | 2021-01-24 08:49:20 | -0.3 | y | 44 | 335 | |||
| IIEES SC | KHMZ | Z | IP | I | 2021-01-24 08:49:43 | -0.3 | y | 200 | 18 | |||
| IIEES SC | KLNJ | Z | IP | I | 2021-01-24 08:49:49 | -0.9 | y | 244 | 119 | |||
| IIEES SC | ASAO | Z | IP | I | 2021-01-24 08:49:55 | 0.4 | y | 278 | 13 | |||
| IIEES SC | GHVR | Z | IP | I | 2021-01-24 08:49:59 | 0.3 | y | 322 | 34 | |||
| IIEES SC | SNGE | Z | IP | I | 2021-01-24 08:50:07 | 0.2 | y | 378 | 331 | |||
| IIEES SC | QABG | Z | IP | I | 2021-01-24 08:50:10 | 0.3 | y | 400 | 3 | |||
| IIEES SC | CHTH | Z | IP | I | 2021-01-24 08:50:16 | -0.2 | y | 455 | 21 | |||
| IIEES SC | DAMV | Z | IP | I | 2021-01-24 08:50:17 | -0.1 | y | 467 | 32 | |||
| IIEES SC | YZKH | Z | IP | I | 2021-01-24 08:50:22 | 0.9 | y | 500 | 86 | |||
| IIEES SC | MEH | Z | IP | I | 2021-01-24 08:50:23 | 1.1 | n | 4 | 511 | 98 | ||
| IIEES SC | SRSL | Z | IP | I | 2021-01-24 08:50:35 | 3.3 | n | 4 | 589 | 322 | ||
| IIEES SC | GLO | Z | IP | I | 2021-01-24 08:50:40 | 0.4 | y | 644 | 40 | |||
| IIEES SC | GLO | Z | IVmB_BB | 2021-01-24 08:51:04 | y | 1 | 644 | 40 | ||||
