Magnitude |
:3.3 |
| Date & Time (UTC) | 2021-11-12 11:10:30.8 |
| Date & Time (Local) | 1400/8/21 14:40:30.8 |
| Location | Lat:32.294 Lon: 49.664 |
| Region | Khoozestan Province, 47 km South-West of Chelgard |
Nearest Cities |
|
| 10 km North East of Paabshalal, Khoozestan Province | |
| 23 km North East of Qale-yekhvaju, Khoozestan Province | |
| 36 km North West of Torshak, Khoozestan Province | |
| 47 km South West of Chelgard, Chaharmahal Bakhtiari Province | |
| 48 km South West of Durak, Chaharmahal Bakhtiari Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| MFF2 (Length: 205 km) , Distance to epicenter: 15 km | |
| ZARDKUH_F (Length: 139 km) , Distance to epicenter: 35 km | |
| ARDAL_F (Length: 170 km) , Distance to epicenter: 44 km | |
| Number of Phases | 11 |
| RMS | 0.6 |
| Number of Stations | 11 |
| Error in Latitude | >2.8 km |
| Error in Longitude | 2.8 km |
| Error in Depth | 5.5 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 166230 | IIEES SC | GTMR | Z | 5 | 1 | 2021-11-12 11:10:41 | 2021-11-13 07:34:00 | n |
| 166231 | IIEES SC | KHMZ | Z | 0.6 | 1 | 2021-11-12 11:10:56 | 2021-11-13 07:34:00 | n |
| 166232 | IIEES SC | KLNJ | Z | 0.4 | 1 | 2021-11-12 11:11:07 | 2021-11-13 07:34:00 | n |
| 166233 | IIEES SC | ASAO | Z | 0.3 | 1 | 2021-11-12 11:11:11 | 2021-11-13 07:34:00 | n |
| 166234 | IIEES SC | GHVR | Z | 0.3 | 1 | 2021-11-12 11:11:14 | 2021-11-13 07:34:00 | n |
| 166235 | IIEES SC | NASN | Z | 0.1 | 1 | 2021-11-12 11:11:17 | 2021-11-13 07:34:00 | n |
| 166236 | IIEES SC | ILBA | Z | 0.07 | 1 | 2021-11-12 11:11:22 | 2021-11-13 07:34:00 | n |
| 166237 | IIEES SC | SNGE | Z | 0.1 | 1 | 2021-11-12 11:11:25 | 2021-11-13 07:34:00 | n |
| 166238 | IIEES SC | CHTH | Z | 0.04 | 1 | 2021-11-12 11:11:30 | 2021-11-13 07:34:00 | n |
| 166239 | IIEES SC | GZV | Z | 0.1 | 1 | 2021-11-12 11:11:36 | 2021-11-13 07:34:00 | n |
| 166240 | IIEES SC | YZKH | Z | 0.04 | 1 | 2021-11-12 11:11:36 | 2021-11-13 07:34:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | GTMR | Z | EPg | E | 2021-11-12 11:10:41 | 0.4 | y | 0 | 56 | 291 | ||
| IIEES SC | KHMZ | Z | EPg | E | 2021-11-12 11:10:56 | -1.1 | y | 0 | 163 | 10 | ||
| IIEES SC | KLNJ | Z | EPn | E | 2021-11-12 11:11:07 | -0.1 | y | 0 | 232 | 128 | ||
| IIEES SC | ASAO | Z | EPn | E | 2021-11-12 11:11:11 | 0.8 | y | 0 | 252 | 8 | ||
| IIEES SC | GHVR | Z | EPn | E | 2021-11-12 11:11:14 | 0.7 | y | 0 | 284 | 31 | ||
| IIEES SC | NASN | Z | EPn | E | 2021-11-12 11:11:17 | 0.8 | y | 0 | 301 | 79 | ||
| IIEES SC | ILBA | Z | EPn | E | 2021-11-12 11:11:22 | -0.7 | y | 0 | 355 | 295 | ||
| IIEES SC | SNGE | Z | EPn | E | 2021-11-12 11:11:25 | -0.6 | y | 0 | 378 | 325 | ||
| IIEES SC | CHTH | Z | EPn | E | 2021-11-12 11:11:30 | -0.8 | y | 0 | 423 | 19 | ||
| IIEES SC | GZV | Z | EPn | E | 2021-11-12 11:11:36 | 0.6 | y | 0 | 457 | 6 | ||
| IIEES SC | YZKH | Z | EPn | E | 2021-11-12 11:11:36 | -0.3 | y | 0 | 464 | 89 | ||
