Magnitude |
:3.8 |
| Date & Time (UTC) | 2023-10-23 08:14:03.0 |
| Date & Time (Local) | 1402/8/1 11:44:03.0 |
| Location | Lat:29.572 Lon: 53.488 |
| Region | Fars Province, 41 km South-East of Arsanjan |
Nearest Cities |
|
| 14 km East of Sofla, Fars Province | |
| 23 km North East of Kafdahak, Fars Province | |
| 26 km South East of Shurab, Fars Province | |
| 29 km East of Dehqanan, Fars Province | |
| 32 km South East of Khabriz, Fars Province | |
| Depth | 12 km |
| Agency | |
Faults within 150 km: |
|
| SARVESTAN_F (Length: 94 km) , Distance to epicenter: 25 km | |
| BAKHTEGAN_F (Length: 94 km) , Distance to epicenter: 30 km | |
| HZF3 (Length: 197 km) , Distance to epicenter: 30 km | |
| Number of Phases | 17 |
| RMS | 0.5 |
| Number of Stations | 17 |
| Error in Latitude | >1.7 km |
| Error in Longitude | 1.7 km |
| Error in Depth | 541.7 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 188353 | IIEES SC | KLNJ | Z | 1 | 1 | 2023-10-23 08:14:41 | 2023-10-23 10:14:00 | n |
| 188354 | IIEES SC | TAFT | Z | 1 | 1 | 2023-10-23 08:14:42 | 2023-10-23 10:14:00 | n |
| 188355 | IIEES SC | LMD1 | Z | 2 | 1 | 2023-10-23 08:14:42 | 2023-10-23 10:14:00 | n |
| 188356 | IIEES SC | YZKH | Z | 0.4 | 1 | 2023-10-23 08:14:52 | 2023-10-23 10:14:00 | n |
| 188357 | IIEES SC | BNDS | Z | 0.2 | 1 | 2023-10-23 08:14:54 | 2023-10-23 10:14:00 | n |
| 188358 | IIEES SC | NASN | Z | 0.1 | 1 | 2023-10-23 08:14:56 | 2023-10-23 10:14:00 | n |
| 188359 | IIEES SC | KBAM | Z | 0.1 | 1 | 2023-10-23 08:15:11 | 2023-10-23 10:14:00 | n |
| 188360 | IIEES SC | GTMR | Z | 0.2 | 1 | 2023-10-23 08:15:15 | 2023-10-23 10:14:00 | n |
| 188361 | IIEES SC | TABS | Z | 0.1 | 1 | 2023-10-23 08:15:21 | 2023-10-23 10:14:00 | n |
| 188362 | IIEES SC | UOSS | Z | 0.1 | 1 | 2023-10-23 08:15:22 | 2023-10-23 10:14:00 | n |
| 188363 | IIEES SC | GHVR | Z | 0.2 | 1 | 2023-10-23 08:15:23 | 2023-10-23 10:14:00 | n |
| 188364 | IIEES SC | BSRN | Z | 0.06 | 1 | 2023-10-23 08:15:26 | 2023-10-23 10:14:00 | n |
| 188365 | IIEES SC | QABG | Z | 0.008 | 1 | 2023-10-23 08:15:46 | 2023-10-23 10:14:00 | n |
| 188366 | IIEES SC | ABGH | Z | 0.04 | 1 | 2023-10-23 08:15:51 | 2023-10-23 10:14:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | MEH | Z | EPn | E | 2023-10-23 08:14:40 | 0.9 | y | 0 | 229 | 28 | ||
| IIEES SC | KLNJ | Z | EPn | E | 2023-10-23 08:14:41 | 0.1 | y | 0 | 242 | 311 | ||
| IIEES SC | TAFT | Z | EPn | E | 2023-10-23 08:14:42 | 0.7 | y | 0 | 247 | 15 | ||
| IIEES SC | LMD1 | Z | EPn | E | 2023-10-23 08:14:42 | 0.3 | y | 0 | 249 | 187 | ||
| IIEES SC | YZKH | Z | EPn | E | 2023-10-23 08:14:52 | 0.6 | y | 0 | 330 | 19 | ||
| IIEES SC | BNDS | Z | EPn | E | 2023-10-23 08:14:54 | -0.4 | y | 0 | 356 | 132 | ||
| IIEES SC | NASN | Z | EPn | E | 2023-10-23 08:14:56 | -0.3 | y | 0 | 364 | 350 | ||
| IIEES SC | KBAM | Z | EPn | E | 2023-10-23 08:15:11 | 0.3 | y | 0 | 484 | 96 | ||
| IIEES SC | GTMR | Z | EPn | E | 2023-10-23 08:15:15 | -0.8 | y | 0 | 527 | 308 | ||
| IIEES SC | TABS | Z | EPn | E | 2023-10-23 08:15:21 | -0.5 | y | 0 | 568 | 37 | ||
| IIEES SC | UOSS | Z | EPn | E | 2023-10-23 08:15:22 | -0.8 | y | 0 | 579 | 152 | ||
| IIEES SC | GHVR | Z | EPn | E | 2023-10-23 08:15:23 | 0.3 | y | 0 | 584 | 339 | ||
| IIEES SC | BSRN | Z | EPn | E | 2023-10-23 08:15:26 | 0.2 | y | 0 | 602 | 64 | ||
| IIEES SC | ANJ | Z | EPn | E | 2023-10-23 08:15:32 | -0.2 | y | 0 | 655 | 4 | ||
| IIEES SC | QABG | Z | EPn | E | 2023-10-23 08:15:46 | -0.8 | y | 0 | 773 | 332 | ||
| IIEES SC | ABGH | Z | EPn | E | 2023-10-23 08:15:51 | 0.3 | y | 0 | 804 | 9 | ||
| IIEES SC | DHR | Z | EPn | E | 2023-10-23 08:15:59 | -0.4 | y | 0 | 879 | 310 | ||
