Magnitude |
:3.7 |
| Date & Time (UTC) | 2024-08-20 01:46:43.9 |
| Date & Time (Local) | 1403/5/30 05:16:43.9 |
| Location | Lat:32.15 Lon: 55.983 |
| Region | Yazd Province, 82 km North-East of Bafq |
Nearest Cities |
|
| 31 km North of Behabad, Yazd Province | |
| 47 km North of Benestan, Yazd Province | |
| 49 km North East of Kushk, Yazd Province | |
| 58 km North West of Asfih, Yazd Province | |
| 75 km North of Basab, Yazd Province | |
| Depth | 8 km |
| Agency | |
Faults within 150 km: |
|
| JAFARABAD_F (Length: 60 km) , Distance to epicenter: 3 km | |
| SARBALA_F (Length: 92 km) , Distance to epicenter: 14 km | |
| KUHBANAN_F (Length: 189 km) , Distance to epicenter: 17 km | |
| Number of Phases | 17 |
| RMS | 0.3 |
| Number of Stations | 17 |
| Error in Latitude | >1.4 km |
| Error in Longitude | 1.4 km |
| Error in Depth | 12.1 km |
Download waveform in seisan format
to download seisan software Click here
to access information about IIEES stations Click here
Amplitude | ||||||||
| UID | Agency | Station | Component | Amplitude | Period | Arrival Time | Proccessing Time | Signal Clip |
| 194583 | IIEES SC | TABS | Z | 2 | 1 | 2024-08-20 01:47:16 | 2024-08-20 03:52:00 | n |
| 194584 | IIEES SC | BSRN | Z | 0.6 | 1 | 2024-08-20 01:47:29 | 2024-08-20 03:52:00 | n |
| 194585 | IIEES SC | NASN | Z | 0.7 | 1 | 2024-08-20 01:47:30 | 2024-08-20 03:52:00 | n |
| 194586 | IIEES SC | SHRT | Z | 0.3 | 1 | 2024-08-20 01:47:46 | 2024-08-20 03:52:00 | n |
| 194587 | IIEES SC | GHVR | Z | 0.2 | 1 | 2024-08-20 01:47:56 | 2024-08-20 03:52:00 | n |
| 194588 | IIEES SC | BNDS | Z | 0.08 | 1 | 2024-08-20 01:47:58 | 2024-08-20 03:52:00 | n |
| 194589 | IIEES SC | ZHSF | Z | 0.05 | 1 | 2024-08-20 01:47:58 | 2024-08-20 03:52:00 | n |
| 194590 | IIEES SC | MRVT | Z | 0.05 | 1 | 2024-08-20 01:48:08 | 2024-08-20 03:52:00 | n |
| 194591 | IIEES SC | ASAO | Z | 0.05 | 1 | 2024-08-20 01:48:08 | 2024-08-20 03:52:00 | n |
| 194592 | IIEES SC | BJRD | Z | 0.02 | 1 | 2024-08-20 01:48:10 | 2024-08-20 03:52:00 | n |
| 194593 | IIEES SC | IRSR | Z | 0.01 | 1 | 2024-08-20 01:48:25 | 2024-08-20 03:52:00 | n |
Phase | ||||||||||||
| Agency | Station | Component | Phase Type | Phase Quality | First Motion | Observed Arrival Time | Time Residual | Loc. Flag | Input Weight | Distance | Azimuth | |
| IIEES SC | YZKH | Z | EPg | E | 2024-08-20 01:46:38 | -28.4 | n | 4 | 134 | 281 | ||
| IIEES SC | TABS | Z | EPg | E | 2024-08-20 01:47:16 | -0.2 | y | 0 | 197 | 33 | ||
| IIEES SC | KRBR | Z | EPn | E | 2024-08-20 01:47:19 | -4.8 | n | 4 | 252 | 163 | ||
| IIEES SC | BSRN | Z | EPn | E | 2024-08-20 01:47:29 | -0.1 | y | 0 | 298 | 94 | ||
| IIEES SC | NASN | Z | EPn | E | 2024-08-20 01:47:30 | -0.2 | y | 0 | 307 | 284 | ||
| IIEES SC | SHRO | Z | EPn | E | 2024-08-20 01:47:39 | -5.6 | n | 4 | 428 | 0 | ||
| IIEES SC | SHRT | Z | EPn | E | 2024-08-20 01:47:46 | -0.1 | y | 0 | 436 | 68 | ||
| IIEES SC | GHVR | Z | EPn | E | 2024-08-20 01:47:56 | 0.3 | y | 0 | 511 | 300 | ||
| IIEES SC | GHIR | Z | EPn | E | 2024-08-20 01:47:56 | -0.3 | y | 0 | 516 | 214 | ||
| IIEES SC | BNDS | Z | EPn | E | 2024-08-20 01:47:58 | 0.5 | y | 0 | 527 | 178 | ||
| IIEES SC | DAMV | Z | EPn | E | 2024-08-20 01:47:49 | -9.2 | n | 4 | 536 | 316 | ||
| IIEES SC | ZHSF | Z | EPn | E | 2024-08-20 01:47:58 | -0.7 | y | 0 | 537 | 122 | ||
| IIEES SC | MRVT | Z | EPn | E | 2024-08-20 01:48:08 | 0.5 | y | 0 | 611 | 1 | ||
| IIEES SC | ASAO | Z | EPn | E | 2024-08-20 01:48:08 | -0.3 | y | 0 | 615 | 296 | ||
| IIEES SC | BJRD | Z | EPn | E | 2024-08-20 01:48:10 | 0.4 | y | 0 | 629 | 12 | ||
| IIEES SC | KAGH | Z | EPn | E | 2024-08-20 01:48:12 | 0.4 | y | 0 | 644 | 34 | ||
| IIEES SC | IRSR | Z | EPn | E | 2024-08-20 01:48:25 | 0.3 | y | 0 | 744 | 141 | ||
